High Shear Inline Homogenizer Mixer for Cosmetic and Food Emulsion
Product Details
Product Description
High Shear Inline Homogenizer Mixer for Cosmetic & Food Emulsion Production
Professional-grade inline high shear mixer with multi-stage rotor-stator technology. Achieves 1-5 micron particle size for stable emulsions — designed for continuous production in cosmetics, food, and chemical processing. SS316L construction, CE & ISO 9001 certified.
Core Features & Benefits
| Feature | What It Does | Your Benefit |
|---|---|---|
| Multi-Stage Rotor-Stator | 3-stage shear zones with progressive gap reduction | 1-5 micron particle size, stable emulsion |
| Continuous Inline Design | Mixes directly in the pipeline, no batch tank needed | 30-50% faster cycle time vs batch mixing |
| SS316L Product Contact | Pharmaceutical-grade mirror-polished surfaces | GMP compliant, easy CIP cleaning |
| VFD Speed Control | 0-3,600 RPM variable frequency drive | Fine-tune shear intensity per product recipe |
| Double Mechanical Seal | With cooling flush system | Zero leakage, long service life |
| Compact Skid-Mounted Design | Plug-and-play, pre-wired and pre-piped | Easy installation in existing production lines |
Technical Specifications
| Parameter | Specification |
|---|---|
| Flow Rate | 500 - 5,000 L/h |
| Motor Power | 4 - 37 kW |
| Speed Range | 0-3,600 RPM (VFD) |
| Material | SS316L (product contact) |
| Stages | 1-3 stages (configurable) |
| Inlet/Outlet | DN40 / DN50 tri-clamp |
| Particle Size | 1-5 μm (typical) |
| Voltage | 220V / 380V / 440V, 50Hz/60Hz, 3-Phase |
Industries & Applications
| Industry | Application |
|---|---|
| Cosmetics | Creams, lotions, serums, sunscreen emulsions |
| Food & Beverage | Mayonnaise, dressings, sauces, dairy emulsions |
| Chemicals | Surfactant blends, polymer dispersions, wax emulsions |
| Paints & Coatings | Pigment pastes, color dispersions |
Why Choose Vison Chemicals
Inline continuous mixing reduces batch time by up to 50% vs traditional tank mixers
CE & ISO 9001 certified manufacturing — consistent quality, batch after batch
OEM/ODM customization available — motor power, stages, and controls to your spec
Pre-shipment QC video inspection — verify your equipment before it leaves the factory
18-language global support — spare parts shipped within 48 hours
