20TPD SS316L Calcium Chloride Production Line for Concrete Accelerator De-icing and Water Treatment Chemicals

1 Set (Sample Order Welcome)
MOQ
Custom Quote
Price
20TPD SS316L Calcium Chloride Production Line for Concrete Accelerator De-icing and Water Treatment Chemicals
Features Gallery Product Description Request A Quote
Features
Specifications
Application: Calcium Chloride Production, Concrete Accelerator Manufacturing, De-icing Agent Production, Dust Control Agent, Desiccant Production, Water Treatment Chemical, Oilfield Brine Additive
Material: SS304 / SS316L
After-sales Service: Online Support, Field Installation & Commissioning
Warranty: 1 Year
Automation Level: Fully Automatic PLC / Semi-Automatic
Control System: PLC + HMI Touchscreen
Agitator Type: Top Entry Turbine / Anchor With VFD
Heating Method: Steam Heating For Evaporation And Drying
Weighing Accuracy: ±0.5% Load Cell Batching
Capacity Range: 5 - 50 Ton/Day Calcium Chloride Output
Highlight:

calcium chloride production line

,

calcium chloride manufacturing plant

,

calcium chloride flakes production equipment

,

calcium chloride drying and flaking line
Basic Infomation
Place of Origin: Guangzhou, China
Brand Name: Vison Chemicals
Certification: CE, ISO9001
Model Number: VC-CaCl2-20T
Payment & Shipping Terms
Packaging Details: Export Plywood Case with Moisture Barrier
Delivery Time: 30-45 Days (Expedited)
Payment Terms: T/T 30% Advance + L/C at Sight
Supply Ability: 20+ Sets/Month
Product Description

SS316L Calcium Chloride Production Line for Concrete Accelerator De-icing Agent and Water Treatment Chemical Manufacturing

Vison Chemicals manufactures SS316L calcium chloride production lines engineered for the continuous manufacturing of calcium chloride flakes, pellets and powder from hydrochloric acid and limestone neutralization. Each calcium chloride production line integrates an acid-resistant neutralization reactor, a multi-effect evaporator for concentration, a drum flaker for flake crystallization, and a drying and packaging section. The SS316L wetted parts resist the hot hydrochloric acid and chloride brine, while PLC control keeps pH, concentration and temperature stable for concrete accelerator, de-icing agent, desiccant and water treatment chemical applications.

Key Features

  • SS316L wetted parts resist corrosion from hydrochloric acid and hot calcium chloride brine during neutralization and evaporation
  • Acid-resistant neutralization reactor with HCl dosing reacts hydrochloric acid with limestone or slaked lime to form the calcium chloride solution
  • Multi-effect evaporator concentrates the calcium chloride solution to the required flake or pellet feed concentration with low steam consumption
  • Drum flaker converts concentrated calcium chloride brine into 74-77% flakes, with optional drying for 94%+ anhydrous pellets
  • PLC and HMI control of pH, temperature and concentration delivers consistent output for concrete accelerator and de-icing agent production
  • CE and ISO9001 certified manufacturing with field installation and commissioning support

Technical Specifications

ParameterSpecification
Production Capacity5 - 50 Ton/Day Calcium Chloride
Wetted MaterialSS316L (SS304 Optional)
NeutralizationHCl + Limestone / Slaked Lime Reactor
ConcentrationMulti-Effect Evaporator
Final FormFlakes / Pellets / Powder
Automation LevelFully Automatic PLC / Semi-Automatic
Control SystemPLC + HMI Touchscreen
Heating MethodSteam Heating for Evaporation and Drying

Applications

IndustryWhat You Can MakeRecommended Config
ConstructionConcrete set accelerator and cold weather concrete admixtureSS316L line + flaker
Road & HighwayDe-icing agent and dust control agentSS316L line + pellet dryer
Water TreatmentCalcium chloride brine for hardness control and flocculant aidSS316L reactor + evaporator
Oil & GasDrilling and completion brine and cement acceleratorSS316L line + filtration
Desiccant & DryingDesiccant granules and moisture absorberSS316L line + anhydrous dryer
Food ProcessingFood grade firming agent for cheese and canned vegetablesSS304 sanitary line

Why Choose Us

  • Vison Chemicals is a Guangzhou based manufacturer and factory of stainless steel production lines and chemical processing equipment
  • OEM and ODM support with process design, evaporator sizing and calcium chloride line layout consultation
  • CE and ISO9001 certified production with export experience to construction, water treatment and chemical factories worldwide
  • Field installation, commissioning and after-sales support for overseas buyers
For calcium chloride production line pricing, specifications and catalog, contact Vison Chemicals.
Email: minvison@163.com | Web: www.mixing-tanks.com

#CalciumChloride #CalciumChlorideProductionLine #ConcreteAccelerator #DeIcingAgent #DustControlAgent #Desiccant #WaterTreatmentChemical #OilfieldBrine #SS316LProductionLine #ChemicalProductionLine #Evaporator #Flaker #VisonChemicals
